FCC-4AT SERIES     SMT POWER INDUCTORS
* Available in surface mount packaging
* Low profile (Molding type)
* Suitable for reflow soldering
* Customer special design

Part Inductance DC. R Rated Current Test Freq.
Number (uH20%) ( max.) (A max.) (F)
FCC-4AT-100 10 0.08 1.50 100 KHz
FCC-4AT-120 12 0.09 1.40 100 KHz
FCC-4AT-150 15 0.11 1.30 100 KHz
FCC-4AT-180 18 0.12 1.10 100 KHz
FCC-4AT-220 22 0.14 1.00 100 KHz
FCC-4AT-270 27 0.16 0.92 100 KHz

* Operating temperature : -40'C to +85'C
