FCC-5845 SERIES |
|
SMT
POWER INDUCTORS |
|
|
| * Available in surface
mount packaging |
|
| * Low profile
|
|
| * Suitable for reflow
soldering |
|
| * Low cost
|
|
| * Customer
special design |
|
| |
| Part |
Inductance |
DC. R |
Rated Current |
TEST FREQ. |
| Number |
(uH¡¾20%)
|
(§Ù max.) |
(A max.) |
(F) |
| FCC-5845-100 |
10 |
0.10 |
1.44 |
2.52 MHz |
| FCC-5845-120 |
12 |
0.12 |
1.40 |
2.52 MHz |
| FCC-5845-150 |
15 |
0.14 |
1.30 |
2.52 MHz |
| FCC-5845-180 |
18 |
0.15 |
1.23 |
2.52 MHz |
| FCC-5845-220 |
22 |
0.18 |
1.12 |
2.52 MHz |
| FCC-5845-270 |
27 |
0.20 |
0.96 |
2.52 MHz |
| FCC-5845-330 |
33 |
0.23 |
0.88 |
2.52 MHz |
| FCC-5845-390 |
39 |
0.32 |
0.80 |
2.52 MHz |
| FCC-5845-470 |
47 |
0.37 |
0.72 |
2.52 MHz |
| FCC-5845-560 |
56 |
0.42 |
0.68 |
2.52 MHz |
| FCC-5845-680 |
68 |
0.46 |
0.60 |
2.52 MHz |
| FCC-5845-820 |
82 |
0.60 |
0.58 |
2.52 MHz |
| FCC-5845-101 |
100 |
0.70 |
0.52 |
1.00 KHz |
| FCC-5845-121 |
120 |
0.94 |
0.48 |
1.00 KHz |
| FCC-5845-151 |
150 |
1.10 |
0.40 |
1.00 KHz |
| FCC-5845-181 |
180 |
1.38 |
0.38 |
1.00 KHz |
| FCC-5845-221 |
220 |
1.57 |
0.35 |
1.00 KHz |
| FCC-5845-331 |
330 |
1.80 |
0.30 |
1.00 KHz |
| |
| * Operating temperature
: -40'C to +85'C |
|
|
