FCC-127 SERIES
|
SMT POWER INDUCTORS |
|
|
| * Available in surface
mount packaging |
| * Magnetically shielded
|
| * Suitable for reflow
soldering |
| * Low cost
|
| * Customer special
design |
| |
|
Part |
Inductance |
DC. R |
Rated Current |
Test Freq. |
|
Number |
(uH¡¾20%)
|
(§Ù max.) |
(A max.) |
(F) |
|
FCC-127-100 |
10 |
0.025 |
4.00 |
1 KHz |
|
FCC-127-120 |
12 |
0.027 |
3.50 |
1 KHz |
|
FCC-127-150 |
15 |
0.030 |
3.30 |
1 KHz |
|
FCC-127-180 |
18 |
0.034 |
3.00 |
1 KHz |
|
FCC-127-220 |
22 |
0.036 |
2.80 |
1 KHz |
|
FCC-127-270 |
27 |
0.051 |
2.30 |
1 KHz |
|
FCC-127-330 |
33 |
0.057 |
2.10 |
1 KHz |
|
FCC-127-390 |
39 |
0.068 |
2.00 |
1 KHz |
|
FCC-127-470 |
47 |
0.075 |
1.80 |
1 KHz |
|
FCC-127-560 |
56 |
0.11 |
1.70 |
1 KHz |
|
FCC-127-680 |
68 |
0.12 |
1.50 |
1 KHz |
|
FCC-127-820 |
82 |
0.14 |
1.40 |
1 KHz |
|
FCC-127-101 |
100 |
0.16 |
1.30 |
1 KHz |
|
FCC-127-121 |
120 |
0.17 |
1.10 |
1 KHz |
|
FCC-127-221 |
220 |
0.40 |
0.80 |
1 KHz |
|
FCC-127-331 |
330 |
0.51 |
0.68 |
1 KHz |
|
FCC-127-471 |
470 |
0.77 |
0.58 |
1 KHz |
|
FCC-127-561 |
560 |
0.86 |
0.54 |
1 KHz |
| |
|
|
|
|
| |
|
|
|
|
| * Operating temperature
: -40'C to +85'C |
|
|
|
