FCC-4DT SERIES
|
|
SMT POWER INDUCTORS |
|
|
| * Available
in surface mount packaging
|
| * Low profile
|
Typical inductance
vs. current
|
| * Low cost |
|
| * Customer
special design |
| |
|
Part |
Inductance |
DC. R |
Rated Current |
Raited L |
|
Number |
(uH¡¾20%)
|
(§Ù max.) |
(A max.) |
(uH min.) |
|
|
|
|
|
|
FCC-4DT-102 |
1.0 |
0.045 |
2 |
0.6 |
|
FCC-4DT-152 |
1.5 |
0.050 |
1.9 |
0.8 |
|
FCC-4DT-222 |
2.2 |
0.060 |
1.5 |
0.9 |
|
FCC-4DT-332 |
3.3 |
0.070 |
1.2 |
1.5 |
|
FCC-4DT-472 |
4.7 |
0.080 |
1.2 |
2.0 |
|
FCC-4DT-682 |
6.8 |
0.085 |
1 |
3.0 |
|
FCC-4DT-103 |
10 |
0.095 |
0.70 |
5.0 |
|
FCC-4DT-153 |
15 |
0.135 |
0.60 |
6.0 |
Typical inductance
vs. current
|
|
FCC-4DT-223 |
22 |
0.160 |
0.50 |
10 |
|
|
FCC-4DT-333 |
33 |
0.275 |
0.45 |
12 |
|
FCC-4DT-473 |
47 |
0.550 |
0.35 |
20 |
|
FCC-4DT-683 |
68 |
0.575 |
0.29 |
30 |
|
FCC-4DT-104 |
100 |
1.10 |
0.24 |
40 |
|
FCC-4DT-154 |
150 |
1.40 |
0.21 |
60 |
|
FCC-4DT-224 |
220 |
2.25 |
0.17 |
90 |
|
FCC-4DT-334 |
330 |
2.90 |
0.16 |
100 |
|
FCC-4DT-474 |
470 |
3.60 |
0.14 |
150 |
|
FCC-4DT-684 |
680 |
4.55 |
0.12 |
200 |
|
|
| |
|
* Inductance tested at 100KHz 0.1V. |
| * Operating
temperature : -40'C to +85'C |
