| SMD Type Transformer | |||||||||||||||||||||||
| |||||||||||||||||||||||
| TYPE | SIZE | MATERIAL | FEATURE |
| EPC CORE TYPE | EPC 7, 10, 13, 17, 19, 25 | Mn-Zn Ferrite | Fig.¨ç |
| EER CORE TYPE | EER 9.5, 11, 14.5 | Mn-Zn Ferrite | Fig.¨è |
| TOROIDAL TYPE(ø) | 2, 2.7, 4, 7, 8, 10, 13, 15 | Mn-Zn Ferrite Ni-Zn Ferrite Permalloy |
Fig.¨é |
| LE CORE TYPE (mm) | 8, 12.7, 16, 19 | Pemalloy(Ni:80%) | Fig.¨ê |
| LE CORE TYPE | EE 5, 8.3, 10, 13, 16, 19 | Mn-Zn Ferrite | Fig.¨ë |
